There is a 10 day lead time on Combo-flo noids ....so schedule accordingly.
Mini Airnoids
For Nozzle Fogger Systems or Plates
"Fuel"
"Nitrous"
Ultra small, light weight, highest flow.
Due to their High pressure rating the fuel noids can also be used for EFI applications.
IF you have even higher psi demands such as mechanical fuel injection the nitrous noid can be used as a fuel noid.
Due to their High pressure rating the fuel noids can also be used for EFI applications.
IF you have even higher psi demands such as mechanical fuel injection the nitrous noid can be used as a fuel noid.
Size comparison photos
Click to enlarge
"Nitrous"
"Fuel"
Dimensions: std.... 2.43" x 1.5" x 1.00"
w Dist Block:........... 3.67" x 1.5" x 1.00"
Weight: Std ............ 104 grams (3.67 oz)
w Dist block ............120 grams (4.23 oz)
Orifice: .................... .156
Ports: .......................1/4npt in, 1/8npt out
Piston Material:....... Teflon
Piston Lift:.............. .125
n2o Flow @ 900 lbs:........... stay tuned
Fuel flow @ 8 lbs....... 626 lbs/hr
Max psi: ...................... 1250 lbs
Amps:.......................... Zero, Nada, ZiP
w Dist Block:........... 3.67" x 1.5" x 1.00"
Weight: Std ............ 104 grams (3.67 oz)
w Dist block ............120 grams (4.23 oz)
Orifice: .................... .156
Ports: .......................1/4npt in, 1/8npt out
Piston Material:....... Teflon
Piston Lift:.............. .125
n2o Flow @ 900 lbs:........... stay tuned
Fuel flow @ 8 lbs....... 626 lbs/hr
Max psi: ...................... 1250 lbs
Amps:.......................... Zero, Nada, ZiP
Dimensions: std.... .2.06" x 1.5" x .625
w Dist Block:............ 3.25" x 1.5" x .625
Weight: Std ............. 60 grams (2.1 oz)
w Dist block.............75 grams (2.65 oz)
Orifice: ..................... .218
Ports: ........................1/8npt in, 1/8npt out
Piston Material:....... Teflon
Piston Lift:............... .125
Flow @ 8 lbs:........... 764.24 lbs/hr
Max fuel psi: .............90 lbs
Amps:........................ Zero, Nada, ZiP
w Dist Block:............ 3.25" x 1.5" x .625
Weight: Std ............. 60 grams (2.1 oz)
w Dist block.............75 grams (2.65 oz)
Orifice: ..................... .218
Ports: ........................1/8npt in, 1/8npt out
Piston Material:....... Teflon
Piston Lift:............... .125
Flow @ 8 lbs:........... 764.24 lbs/hr
Max fuel psi: .............90 lbs
Amps:........................ Zero, Nada, ZiP
Fuel Flow is VP16 @ 70 degrees
Nitrous Noid may be used as a fuel noid for extreme demands
# MR-218 - $118.95
# MB-156 - $160.95
Std w bottom outlet
Std w bottom outlet
# MB-156D- $186.99
# MR-281D- $143.95
W distribution Block
W distribution Block
The Mini Noids can be used on plate systems but note that due to their really small size there are no purpose postioned bracket mounting holes. However, there are some threaded 8-32 holes that you would need to fabricate some custom brackets to fit.
Monster Noid
"The highest flowing, baddest solenoid
on the planet!"
on the planet!"
Fuel
Dimensions:.... 1.38 x1.06 x 2.94
Weight: .... 165 grams (5.82 oz)
Orifice:... .157
Ports: 1/8 in & 1/8" out
Piston material: Teflon
Piston lift: .100
Fuel Flow @ 8 lbs: 585 lbs/hr
Max PSI: 90
2 10-24 bracket holes on 1.1 centers
Amps:... Zero, Nada, ZiP
Weight: .... 165 grams (5.82 oz)
Orifice:... .157
Ports: 1/8 in & 1/8" out
Piston material: Teflon
Piston lift: .100
Fuel Flow @ 8 lbs: 585 lbs/hr
Max PSI: 90
2 10-24 bracket holes on 1.1 centers
Amps:... Zero, Nada, ZiP
Nitrous
Dimensions:.... 1.72 x 1.45 x 3.23
Weight: .... 284 grams (10.02 oz)
Orifice:......
Ports: 1/4npt in, 1/8npt out
1/16 purge port
Piston material: Teflon
Piston lift: .125
n2o Flow @ 900 psi: 4750 lbs/hr
Fuel Flow @ 8 psi: 1004 lbs/hr
Max psi: 1250 lbs
2 10-24 bracket holes on 1.1 centers
Amps:... Zero, Nada, ZiP
Weight: .... 284 grams (10.02 oz)
Orifice:......
Ports: 1/4npt in, 1/8npt out
1/16 purge port
Piston material: Teflon
Piston lift: .125
n2o Flow @ 900 psi: 4750 lbs/hr
Fuel Flow @ 8 psi: 1004 lbs/hr
Max psi: 1250 lbs
2 10-24 bracket holes on 1.1 centers
Amps:... Zero, Nada, ZiP
Side Outlet
#FS500-1 - $129.95
Fuel Flow is VP16 @ 70 degrees
#NS500P - $197.33
(w Purge Port)
Fuel Flow is VP16 @ 70 degrees
Airnoid Actuators
Dimensions:.... 7/8" x 1"x 37/8"
Weight: .... 106 grams (3.7 oz)
Amps:... 0.6 (no relay needed!)
Weight: .... 106 grams (3.7 oz)
Amps:... 0.6 (no relay needed!)
#AV1 - $62.23
Each AV1 Actuator will open: 1 pair of the 500 series Plate Airnoids or 2 n2o and 2 fuel mini noids (4 mini noids).
Dimensions:.... 2" x 1 3/4"x 1"
Weight: .... 445 grams (0.9 lb)
Amps:... 0.6 (no relay needed!)
Weight: .... 445 grams (0.9 lb)
Amps:... 0.6 (no relay needed!)
Can NOT be run with a 9 volt battery!
#AV1 H - $136.95
All Text and images on this website are copyrighted by David Koehler 2000 and beyond
All sales are final. Items and services provided by Koehler Injection are intended for off road use only.
No responsibility whatsoever will be accepted by Koehler Injection for any damage, injury or loss resulting from their use.
No responsibility whatsoever will be accepted by Koehler Injection for any damage, injury or loss resulting from their use.
Urbana IL, USA 217 469 7663 M-F 9 - 5 CST
Postal Money Order
An Actuator is a mini solenoid that takes the signal from your throttle switch, timer or button. When it opens it sends the co2 from the bottle to the Airnoid. Fast action.
1 actuator is required for each stage or you can use one for each Airnoid if you need independent control.
If you wish to activate with air only there are air push buttons and other switches available.
1 actuator is required for each stage or you can use one for each Airnoid if you need independent control.
If you wish to activate with air only there are air push buttons and other switches available.
<<-The AV1 H is a heavy duty hi flow, much faster acting actuator.
You want this one if:
Are feeding more than 2 500 series Plate noids.
You want this one if:
Are feeding more than 2 500 series Plate noids.
100 - 150 psi of Co2, Air, or n2o required
Lighter than electric solenoids (helps resist tire shake breakage)
Higher flow rates in a smaller package than any electric solenoid on the market.
No coils to burn out. No Wires. No Diodes needed. No electric relays to burn up.
Upgrade / Replacement for any brand of electric solenoid.
Will work with any on/off timers.
Can use nitrous to operate in place of Co2.
Perfect for long running applications like Boats or Bonneville.
Can be activated with a 9 volt battery or air switch.
Compatible with any type of alchohol, E85, gas, nitro
Lighter than electric solenoids (helps resist tire shake breakage)
Higher flow rates in a smaller package than any electric solenoid on the market.
No coils to burn out. No Wires. No Diodes needed. No electric relays to burn up.
Upgrade / Replacement for any brand of electric solenoid.
Will work with any on/off timers.
Can use nitrous to operate in place of Co2.
Perfect for long running applications like Boats or Bonneville.
Can be activated with a 9 volt battery or air switch.
Compatible with any type of alchohol, E85, gas, nitro
Can be run with a 9 volt battery!
